CITROEN e-RELAY 35 HEAVY L3

88kW 75kWh H2 Van Enterprise Edition Auto

CITROEN e-RELAY 35 HEAVY L3 88kW 75kWh H2 Van Enterprise Edition Auto

Images are for illustrative purposes only.



Customise Your Lease

An excess mileage charge will apply if you exceed the contract mileage. This will be detailed on your order form

Deal Summary

88kW 75kWh H2 Van Enterprise Edition Auto CITROEN e-RELAY 35 HEAVY L3
Contract type
Contract Term
Initial Rental
Annual Mileage
Maintenance
Additional extras

Fetching your price

Key Information

Transmission
Transmission Automatic
Fuel Type
Fuel Type Electric
Top Speed
Top Speed 75mph
Electric Range
Range 154miles
Real World Estimate
Real World Estimate 131miles
Battery Size
Battery Size 75kWh
Emissions
Co2 0.00g/km
Connector Type
AC Plug Type CCS Type 2

Charging Information

Ultra Rapid(150kW)

Rapid(100kW)

Fast(50kW)

Home(7kW)

Data provided by CAP-HPI database - Ref# 56451

Options

Standard Equipment

Technical Data

Entertainment

Exterior Features

Interior Features

Packs

Paintwork

Passive Safety

Technical

Trim

Wheels

Driver Convenience

  • Battery charge warning
  • Display screen in rear view mirror with traction battery charge level, battery voltage/amperage, and range
  • Door open warning for cab doors
  • Handbrake on warning light
  • Power steering (non variable)
  • Rear parking distance sensor
  • Seatbelt warning indicator

Entertainment

  • 7" Colour touchscreen with DAB radio, integrated satellite navigation, Bluetooth handsfree, USB socket and steering wheel mounted controls
  • Mirrorscreen with Apple CarPlay and Android Auto

Exterior Features

  • Electric front windows
  • Halogen headlights with clear polycarbonate lenses
  • Laminated windscreen
  • Nearside sliding side loading door
  • Non automatic 2 speed intermittent front windscreen wipers
  • Remote headlight adjustment from facia
  • Side protection rubbing strips
  • Tinted windows
  • Twin lens door mirrors with electrically adjustable and heated upper mirror

Interior Features

  • 10 tie-down hooks
  • Bulb out warning for side light,headlamp and indicators
  • Central dash folding clipboard
  • Drivers seat with height, rake, lumbar and reach adjustment, and drivers armrest, with storage compartment under seat
  • Lower central glovebox with dashboard tablet holder
  • Magnet cloth upholstery
  • Manual air conditioning for cab area with glovebox
  • Non illuminated lockable glove box
  • Non slip hardwearing front cabin floor covering
  • Passenger grab handle
  • Reach adjustable steering column
  • Thermostatic heating control
  • Two cup holders and mobile phone storage in centre of lower dashboard
  • Two load area lights

Passive Safety

  • Driver's airbag

Security

  • High frequency remote control central locking with 3 button plip
  • Lights on alarm
  • Locking for cab
  • Perimetric alarm and deadlocks
  • Thatcham rolling transponder immobiliser
  • Visible Vehicle Identification Number (VIN)

Technical

  • 22 kW electric Charging Cable Mode 3 Type 2 for Wallbox
  • ABS
  • Electronic brake force distribution (EBFD)
  • Electronic Stability Control (ESC)
  • Emergency brake assist
  • Hill start assist
  • On board charger-compatible with both single and three phase power supply
  • Reinforced twin leaf rear suspension

Wheels

  • Steel wheel centre cap

Electric Vehicle Data

  • Battery Capacity % guaranteed under warranty
    70
  • Battery Capacity in kWh
    75
  • Battery Charging Scenario 1 - Charge Time (Mins)
    720
  • Battery Charging Scenario 1 - Percentage Change
    0-100
  • Battery Charging Scenario 1 - Power Supply - kW
    7.4
  • Battery Charging Scenario 2 - Charge Time (Mins)
    240
  • Battery Charging Scenario 2 - Percentage Change
    0-100
  • Battery Charging Scenario 2 - Power Supply - kW
    22
  • Battery Charging Scenario 3 - Charge Time (Mins)
    60
  • Battery Charging Scenario 3 - Percentage Change
    0-80
  • Battery Charging Scenario 3 - Power Supply - kW
    60
  • Battery Charging Scenario 4 - Charge Time (Mins)
    Not Available
  • Battery Charging Scenario 4 - Percentage Change
    Not Available
  • Battery Charging Scenario 4 - Power Supply - kW
    Not Available
  • Battery Leased
    No
  • Battery Type
    Lithium-ion
  • Charging Port Location
    Left Side Front
  • Coupler/Connector Type
    CCS Type 2
  • Maximum Charging Rate - kW
    60
  • Standard manufacturers Battery warranty - Mileage
    100000
  • Standard manufacturers Battery warranty - Years
    8
  • Usable Battery Capacity
    Not Available
  • WLTP - Pure Electric Range (km) - Comb
    248
  • WLTP - Pure Electric Range (miles) - Comb
    154

Emissions - ICE

  • Standard Emissions
    Not Available

Engine and Drive Train

  • Automatic Transmission
    Yes
  • CC
    1
  • Fuel Delivery
    Unspecified
  • Fuel Type
    ELECTRIC
  • Gears
    1 SPEED
  • Manual Transmission
    No

Fuel Consumption - ICE

  • EC
    No

General

  • Alternative Fuel Qualifying
    Yes
  • Alternator Amps
    Not Available
  • Did at least one aspect of this vehicles safety give cause for concern?
    No
  • Badge Engine CC
    0.0
  • Badge Power
    120
  • Based On ID
    Not Available
  • Battery AH
    Not Available
  • Battery Volts
    12
  • Chassis Engine Number
    Not Available
  • Clutch
    Not Available
  • Coin Description
    Not Available
  • Coin Gross Vehicle Weight Code
    Not Available
  • Coin Power Output Code
    Not Available
  • Coin Series
    Not Available
  • Coin Wheelbase Description Code
    Not Available
  • Coin Wheelbase Name Code
    Not Available
  • Exhaust System
    Not Available
  • Front Brakes
    VENTILATED DISCS
  • Front Suspension
    MACPHERSON STRUTS
  • Generation Mark
    2
  • Ghost model for valuation purposes
    No
  • Hand Brake
    REAR DRUMS
  • Insurance Group 1
    Not Available
  • Insurance Group 2
    Not Available
  • Manufacturers Corrosion Perforation Guarantee - Years
    6
  • Manufacturers Paintwork Guarantee - Years
    1
  • NCAP Adult Occupant Protection %
    Not Available
  • NCAP Child Occupant Protection %
    Not Available
  • NCAP Front/Side Impact - Discontinued February 09
    Not Available
  • NCAP Overall Rating - Effective February 09
    Not Available
  • NCAP Overall Rating - LCV
    Not Available
  • NCAP Pedestrian - Discontinued February 09
    Not Available
  • NCAP Pedestrian Protection %
    Not Available
  • NCAP Safety Assist %
    Not Available
  • Rear Brakes
    DISCS
  • Rear Suspension
    TWIN LEAF
  • Relative Height
    H2
  • Relative Length
    L3
  • Running Cost League Headings
    LARGE
  • Special Edition
    No
  • Special Order
    No
  • Standard manufacturers warranty - Mileage
    Unlimited
  • Standard manufacturers warranty - Years
    2
  • Steering
    PAS RACK AND PINION
  • Timing Belt Interval Frequency - Months
    Not Available
  • Timing Belt Interval Mileage
    Not Available
  • Vehicle Homologation Class
    N1
  • Vin/Frame No.
    Not Available

Performance

  • BHP
    120
  • Engine Power KW
    90
  • Engine Power RPM
    5500
  • Engine Torque LBS.FT
    258
  • Engine Torque MKG
    35.7
  • Engine Torque NM
    350
  • Top Speed
    75

Test Cycles

  • Emissions Test Cycle
    WLTP
  • RDE Certification Level
    Not Available

Tyres

  • Alloys?
    No
  • Automatic Clutch
    Yes
  • Plated 3rd Axle
    Not Available
  • Plated 4th Axle
    Not Available
  • Space Saver?
    No
  • Tyre Make
    Not Available
  • Tyre Size Front
    215/75 R16
  • Tyre Size Rear
    215/75 R16
  • Tyre Size Spare
    TYRE REPAIR KIT
  • Wheel Style
    Not Available
  • Wheel Type
    16" STEEL

Vehicle Dimensions

  • Front Overhang
    948
  • Height
    2522
  • Height (including roof rails)
    Not Available
  • Length
    5998
  • Load Height
    1932
  • Load Length
    3705
  • Load Space Width Between Wheel Arches
    1422
  • Load Width
    1870
  • Lower Rear Door Width
    1562
  • Rear Door Height
    1790
  • Rear Overhang
    1015
  • Side Load Door Height
    1755
  • Side Load Door Width
    1250
  • Turning Circle - Kerb to Kerb
    14.24
  • Turning Circle - Wall to Wall
    14.46
  • Upper Rear Door Width
    1562
  • Wheelbase
    4035
  • Width (excluding mirrors)
    2050
  • Width (including mirrors)
    2508

Weight and Capacities

  • Boot Capacity Saloons
    Not Available
  • Fuel Tank Capacity (Litres)
    Not Available
  • Gross Vehicle Weight
    3500
  • Load Space Volume
    13
  • Luggage Capacity (Seats Down)
    Not Available
  • Luggage Capacity (Seats Up)
    Not Available
  • Luggage Capacity - 2nd Row Seats Removed
    Not Available
  • Luggage Capacity - 2nd Row Seats Up
    Not Available
  • Luggage Capacity - 3rd Row Seats Down
    Not Available
  • Luggage Capacity - 3rd Row Seats Removed
    Not Available
  • Luggage Capacity - 3rd Row Seats Up
    Not Available
  • Minimum Kerbweight
    2765
  • No. of Seats
    3
  • Payload
    735
  • Plated 2nd Axle
    2400
  • Plated Front Axle
    2100
