CITROEN RELAY 33 L1 DIESEL 2.2 BlueHDi H1 Van 120ps Enterprise Lease Deals

Key Information

Transmission Manual

Fuel Type Diesel

Top Speed 96mph

Co2 154.00g/km

0 - 62mph 0.00s

Engine Size 2.2litres

Data provided by CAP-HPI database - Ref# 44259

Options

Standard Equipment

Technical Data

Driver Convenience

Cruise control with programmable speed limiter
Door open warning for cab doors
Gearshift indicator
Handbrake on warning light
Locking fuel cap
Low fuel warning light
Oil level indicator
Power steering (non variable)
Rev counter, trip computer, water temperature and fuel guage
Seatbelt warning indicator
Telematics box for Free2Move Connect Fleet services including 4G connectivity

Entertainment

5" Colour touchscreen with integrated stellite navigation, Bluetooth handsfree, USB socket and steering wheel mounted controls
USB charging socket on dashboard

Exterior Features

Electric front windows
Halogen headlights with clear polycarbonate lenses
Laminated windscreen
Nearside sliding side loading door
Remote headlight adjustment from facia
Side protection rubbing strips
Tinted windows
Twin lens door mirrors with electrically adjustable and heated upper mirror

Interior Features

8 tie down load hooks
Bulb out side light, headlamp indicator and battery charge warning
Central dash folding clipboard
Driver seat armrest, lumbar adjustable and under seat storage
Driver's seat armrest
Driver's seat with height, rake, reach and lumbar adjustment
Load compartment interior light
Lower central glovebox with dashboard tablet holder
Magnet cloth upholstery
Non illuminated lockable glove box
Non slip hardwearing front cabin floor covering
Passenger grab handle
Reach adjustable steering column
USB charger in load area

Passive Safety

Driver's airbag

Security

High frequency remote control central locking with 3 button plip
Lights on alarm
Locking for cab
Perimetric alarm and deadlocks
Thatcham rolling transponder immobiliser
Visible Vehicle Identification Number (VIN)

Technical

12V socket in load area
ABS
Electronic brake force distribution (EBFD)
Electronic Stability Control (ESC)
Emergency brake assist
Hill start assist

Wheels

15" steel wheels
Full size steel spare wheel
Steel wheel centre cap

Emissions - ICE

CO

0.015
CO2

154
HC

Not Available
HC+NOx

0.031
Noise Level dB(A)

70
NOx

0.026
Particles

0.0004
Standard Emissions

EURO 6
WLTP - CO2 (g/km) - Comb

219
WLTP - CO2 (g/km) - Comb - TEH

282
WLTP - CO2 (g/km) - Comb - TEL

206
WLTP - CO2 (g/km) - Extra High - TEH

317
WLTP - CO2 (g/km) - Extra High - TEL

247
WLTP - CO2 (g/km) - High - TEH

264
WLTP - CO2 (g/km) - High - TEL

182
WLTP - CO2 (g/km) - Low - TEH

270
WLTP - CO2 (g/km) - Low - TEL

201
WLTP - CO2 (g/km) - Medium - TEH

260
WLTP - CO2 (g/km) - Medium - TEL

173

Engine and Drive Train

Automatic Transmission

No
Bore

85
Catalytic Convertor

Yes
CC

2179
Compression Ratio

16.1:1
Cooling System

WATER
Cylinder Layout

IN-LINE
Cylinders

4
Engine Codes

DW12RUE
Engine Layout

FRONT TRANSVERSE
Engine Make

Not Available
Fuel Delivery

COMMON RAIL
Fuel Type

DIESEL
Gears

6 SPEED
Manual Transmission

Yes
Number of Valves

16
Stroke

96
Valve gear

DOHC

Fuel Consumption - ICE

EC

No
WLTP - FC (l/100km) - Comb

8.2
WLTP - FC (l/100km) - Comb - TEH

10.8
WLTP - FC (l/100km) - Comb - TEL

7.8
WLTP - FC (l/100km) - Extra High - TEH

12.1
WLTP - FC (l/100km) - Extra High - TEL

9.4
WLTP - FC (l/100km) - High - TEH

10.1
WLTP - FC (l/100km) - High - TEL

6.9
WLTP - FC (l/100km) - Low - TEH

10.3
WLTP - FC (l/100km) - Low - TEL

7.7
WLTP - FC (l/100km) - Medium - TEH

9.9
WLTP - FC (l/100km) - Medium - TEL

6.6
WLTP - MPG - Comb

34.4
WLTP - MPG - Comb - TEH

26.3
WLTP - MPG - Comb - TEL

36
WLTP - MPG - Extra High - TEH

23.4
WLTP - MPG - Extra High - TEL

30
WLTP - MPG - High - TEH

28.1
WLTP - MPG - High - TEL

40.8
WLTP - MPG - Low - TEH

27.4
WLTP - MPG - Low - TEL

36.9
WLTP - MPG - Medium - TEH

28.4
WLTP - MPG - Medium - TEL

42.9

General

Alternative Fuel Qualifying

No
Did at least one aspect of this vehicles safety give cause for concern?

No
Badge Engine CC

2.2
Badge Power

120
Based On ID

Not Available
Battery Volts

12
Chassis Engine Number

Not Available
Clutch

SINGLE DRY PLATE
Coin Description

Not Available
Coin Gross Vehicle Weight Code

Not Available
Coin Power Output Code

Not Available
Coin Series

Not Available
Coin Wheelbase Description Code

Not Available
Coin Wheelbase Name Code

Not Available
Exhaust System

CATALYTIC CONVERTER
Front Brakes

VENTILATED DISCS
Front Suspension

MACPHERSON STRUTS
Generation Mark

2
Ghost model for valuation purposes

No
Hand Brake

REAR DRUMS
Insurance Group 1

Not Available
Insurance Group 2

Not Available
Manufacturers Corrosion Perforation Guarantee - Years

6
Manufacturers Paintwork Guarantee - Years

1
NCAP Adult Occupant Protection %

Not Available
NCAP Child Occupant Protection %

Not Available
NCAP Overall Rating - Effective February 09

Not Available
NCAP Overall Rating - LCV

Bronze
NCAP Pedestrian Protection %

Not Available
NCAP Safety Assist %

20
Rear Brakes

DISCS
Rear Suspension

LEAF SPRINGS
Relative Height

H1
Relative Length

L1
Running Cost League Headings

LARGE
Service Interval Frequency - Months

24
Service Interval Mileage

32000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

Unlimited
Standard manufacturers warranty - Years

2
Steering

PAS RACK AND PINION
Vehicle Homologation Class

N1
Vin/Frame No.

Not Available

Performance

0 to 62

Not Available
BHP

120
Engine Power KW

88
Engine Power RPM

3500
Engine Torque LBS.FT

229
Engine Torque MKG

31.6
Engine Torque NM

310
Engine Torque RPM

1500
Top Speed

96

Test Cycles

Emissions Test Cycle

WLTP
RDE Certification Level

RDE 2

Tyres

Alloys?

No
Automatic Clutch

No
Plated 3rd Axle

Not Available
Plated 4th Axle

Not Available
Space Saver?

No
Tyre Make

Not Available
Tyre Size Front

215/70 R15
Tyre Size Rear

215/70 R15
Tyre Size Spare

FULL SIZE
Wheel Style

Not Available
Wheel Type

15" STEEL

Vehicle Dimensions

Front Overhang

948
Height

2254
Height (including roof rails)

Not Available
Length

4963
Load Height

1662
Load Length

2670
Load Space Width Between Wheel Arches

1422
Load Width

1870
Lower Rear Door Width

1562
Rear Door Height

1520
Rear Overhang

1015
Side Load Door Height

1485
Side Load Door Width

1075
Turning Circle - Kerb to Kerb

11.26
Turning Circle - Wall to Wall

11.44
Upper Rear Door Width

1562
Wheelbase

3000
Width (excluding mirrors)

2050
Width (including mirrors)

2508

Weight and Capacities

Boot Capacity Saloons

Not Available
Fuel Tank Capacity (Litres)

90
Gross Train Weight

5800
Gross Vehicle Weight

3300
Load Space Volume

8
Luggage Capacity (Seats Down)

Not Available
Luggage Capacity (Seats Up)

Not Available
Luggage Capacity - 2nd Row Seats Removed

Not Available
Luggage Capacity - 2nd Row Seats Up

Not Available
Luggage Capacity - 3rd Row Seats Down

Not Available
Luggage Capacity - 3rd Row Seats Removed

Not Available
Luggage Capacity - 3rd Row Seats Up

Not Available
Max. Roof Load

150
Max. Towing Weight - Braked

2500
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

1875
No. of Seats

3
Payload

1425
Plated 2nd Axle

1900
Plated Front Axle

1800
