CITROEN RELAY 35 L4 DIESEL

2.2 BlueHDi Curtainside 140ps Enterprise Edition

CITROEN RELAY 35 L4 DIESEL 2.2 BlueHDi Curtainside 140ps Enterprise Edition

Images are for illustrative purposes only.



Customise Your Lease

An excess mileage charge will apply if you exceed the contract mileage. This will be detailed on your order form

Deal Summary

2.2 BlueHDi Curtainside 140ps Enterprise Edition CITROEN RELAY 35 L4 DIESEL
Contract type
Contract Term
Initial Rental
Annual Mileage
Maintenance
Additional extras

Fetching your price

Key Information

Transmission
Transmission Manual
Fuel Type
Fuel Type Diesel
Top Speed
Top Speed 99mph
Stopwatch
0 - 62mph 0.00s
Engine Size
Engine Size 2.2litres

Data provided by CAP-HPI database - Ref# 56466

Options

Standard Equipment

Technical Data

Interior Features

Packs

Paintwork

Passive Safety

Trim

Wheels

Driver Convenience

  • Battery charge warning
  • Cruise control with variable speed limiter
  • Door open warning for cab doors
  • Gearshift indicator
  • Handbrake on warning light
  • Locking fuel cap
  • Low fuel warning light
  • Oil level indicator
  • Power steering (non variable)
  • Rev counter, trip computer, water temperature and fuel guage
  • Seatbelt warning indicator
  • Telematics box for Free2Move Connect Fleet services

Entertainment

  • 4 speakers
  • 7" Colour touchscreen with DAB radio, integrated satellite navigation, Bluetooth handsfree, USB socket and steering wheel mounted controls
  • Mirrorscreen with Apple CarPlay and Android Auto

Exterior Features

  • 15mm thick floor
  • Aerodynamic pod with additional storage
  • Daytime running lights
  • Electric front windows
  • Halogen headlights with clear polycarbonate lenses
  • High impact kick strips with side panels and bulkhead protection
  • High quality GRP panels 11mm thick
  • Laminated windscreen
  • Manually folding door mirrors
  • Remote headlight adjustment from facia
  • Solid paint
  • Tinted windows
  • Trifunction aerial in door mirror
  • Twin lens door mirrors with electrically adjustable and heated upper mirror
  • Two speed intermittent front wipers
  • Wider door mirrors - 2200mm

Interior Features

  • 12V socket in cabin
  • Auto illumination of cab light via ceiling mount button
  • Bulb out warning for side light,headlamp and indicators
  • Courtesy light
  • Drivers seat with height, rake, lumbar and reach adjustment, and drivers armrest, with storage compartment under seat
  • Front door armrest
  • Front door bins
  • Front door pockets
  • Height adjustable front headrests
  • Height adjustable steering wheel
  • Interior LED light
  • Internal load locks and tie rails with side panels
  • Magnet cloth upholstery
  • Manual air conditioning for cab area with glovebox
  • Non illuminated lockable glove box
  • Non slip hardwearing front cabin floor covering
  • Passenger grab handle
  • Passengers underseat storage tray
  • Reach adjustable steering column
  • Storage bin in top of dashboard
  • Storage tray
  • Two cup holders and mobile phone storage in centre of lower dashboard
  • Under dash storage areas

Passive Safety

  • Driver's airbag

Security

  • Auto door locking
  • High frequency remote control central locking with 2 button plip
  • Lights on alarm
  • Perimetric alarm and deadlocks
  • Thatcham rolling transponder immobiliser
  • Visible Vehicle Identification Number (VIN)

Technical

  • 12V socket on central dashboard console
  • ABS
  • Electrical connections interface box
  • Electronic brake force distribution (EBFD)
  • Electronic Stability Control (ESC)
  • Emergency brake assist
  • Extended wiring at rear of vehicle
  • Heavy duty reinforced twin leaf rear suspension

Emissions - ICE

  • CO
    Not Available
  • CO2
    186
  • HC
    Not Available
  • HC+NOx
    Not Available
  • Noise Level dB(A)
    Not Available
  • NOx
    Not Available
  • Particles
    Not Available
  • Standard Emissions
    EURO 6
  • WLTP - CO2 (g/km) - Comb
    290
  • WLTP - CO2 (g/km) - Comb - TEH
    351
  • WLTP - CO2 (g/km) - Comb - TEL
    290

Engine and Drive Train

  • Automatic Transmission
    No
  • Bore
    85
  • CC
    2179
  • Cooling System
    WATER
  • Cylinder Layout
    IN-LINE
  • Cylinders
    4
  • Engine Layout
    FRONT TRANSVERSE
  • Engine Make
    Not Available
  • Fuel Delivery
    COMMON RAIL
  • Fuel Type
    DIESEL
  • Gears
    6 SPEED
  • Manual Transmission
    Yes
  • Number of Valves
    16
  • Stroke
    96
  • Valve gear
    DOHC

Fuel Consumption - ICE

  • EC
    Yes
  • WLTP - FC (l/100km) - Comb
    13.4
  • WLTP - FC (l/100km) - Extra High
    17.4
  • WLTP - FC (l/100km) - High
    11.9
  • WLTP - FC (l/100km) - Low
    11.1
  • WLTP - FC (l/100km) - Medium
    11
  • WLTP - MPG - Comb
    21.1
  • WLTP - MPG - Extra High
    16.2
  • WLTP - MPG - High
    23.7
  • WLTP - MPG - Low
    25.4
  • WLTP - MPG - Medium
    25.7

General

  • Alternative Fuel Qualifying
    No
  • Did at least one aspect of this vehicles safety give cause for concern?
    No
  • Badge Engine CC
    2.2
  • Badge Power
    140
  • Based On ID
    Not Available
  • Battery Volts
    12
  • Chassis Engine Number
    Not Available
  • Clutch
    SINGLE DRY PLATE
  • Coin Description
    Not Available
  • Coin Gross Vehicle Weight Code
    Not Available
  • Coin Power Output Code
    Not Available
  • Coin Series
    Not Available
  • Coin Wheelbase Description Code
    Not Available
  • Coin Wheelbase Name Code
    Not Available
  • Exhaust System
    CATALYTIC CONVERTER
  • Front Brakes
    VENTILATED DISCS
  • Front Suspension
    MACPHERSON STRUTS
  • Generation Mark
    2
  • Ghost model for valuation purposes
    No
  • Hand Brake
    REAR DRUMS
  • Insurance Group 1
    Not Available
  • Insurance Group 2
    Not Available
  • Manufacturers Corrosion Perforation Guarantee - Years
    6
  • Manufacturers Paintwork Guarantee - Years
    1
  • NCAP Adult Occupant Protection %
    Not Available
  • NCAP Child Occupant Protection %
    Not Available
  • NCAP Front/Side Impact - Discontinued February 09
    Not Available
  • NCAP Overall Rating - Effective February 09
    Not Available
  • NCAP Overall Rating - LCV
    Bronze
  • NCAP Pedestrian Protection %
    Not Available
  • NCAP Safety Assist %
    20
  • Rear Brakes
    DISCS
  • Rear Suspension
    LEAF SPRINGS
  • Relative Height
    H1
  • Relative Length
    L4
  • Running Cost League Headings
    LARGE
  • Service Interval Frequency - Months
    24
  • Service Interval Mileage
    32000
  • Special Edition
    No
  • Special Order
    No
  • Standard manufacturers warranty - Mileage
    Unlimited
  • Standard manufacturers warranty - Years
    2
  • Steering
    PAS RACK AND PINION
  • Vehicle Homologation Class
    N1
  • Vin/Frame No.
    Not Available

Performance

  • 0 to 62
    Not Available
  • BHP
    140
  • Engine Power KW
    103
  • Engine Power RPM
    3750
  • Engine Torque LBS.FT
    251
  • Engine Torque MKG
    34.7
  • Engine Torque NM
    340
  • Engine Torque RPM
    1750
  • Top Speed
    99

Test Cycles

  • Emissions Test Cycle
    WLTP
  • RDE Certification Level
    RDE 2

Tyres

  • Alloys?
    No
  • Automatic Clutch
    No
  • Plated 3rd Axle
    Not Available
  • Plated 4th Axle
    Not Available
  • Space Saver?
    No
  • Tyre Make
    Not Available
  • Tyre Size Front
    215/70 R15
  • Tyre Size Rear
    215/70 R15
  • Tyre Size Spare
    TYRE REPAIR KIT
  • Wheel Style
    Not Available
  • Wheel Type
    15" STEEL

Vehicle Dimensions

  • Front Overhang
    948
  • Height
    3200
  • Height (including roof rails)
    Not Available
  • Length
    6590
  • Load Deck Height
    Not Available
  • Load Height
    2185
  • Load Length
    4119
  • Load Space Width Between Wheel Arches
    Not Available
  • Load Width
    2083
  • Lower Rear Door Width
    Not Available
  • Rear Door Height
    Not Available
  • Rear Overhang
    1607
  • Side Load Door Height
    Not Available
  • Side Load Door Width
    Not Available
  • Upper Rear Door Width
    Not Available
  • Wheelbase
    4035
  • Width (excluding mirrors)
    2085

Weight and Capacities

  • Fuel Tank Capacity (Litres)
    90
  • Gross Vehicle Weight
    3500
  • Load Space Volume
    18.7
  • Luggage Capacity (Seats Down)
    Not Available
  • Luggage Capacity (Seats Up)
    Not Available
  • Luggage Capacity - 2nd Row Seats Removed
    Not Available
  • Luggage Capacity - 2nd Row Seats Up
    Not Available
  • Luggage Capacity - 3rd Row Seats Down
    Not Available
  • Luggage Capacity - 3rd Row Seats Removed
    Not Available
  • Luggage Capacity - 3rd Row Seats Up
    Not Available
  • Max. Roof Load
    Not Available
  • Minimum Kerbweight
    2559
  • No. of Seats
    3
  • Payload
    941
  • Plated 2nd Axle
    2000
  • Plated Front Axle
    1850
