CITROEN RELAY 40 HEAVY L4 DIESEL 2.2 BlueHDi H2 Van 165ps Enterprise Edition Lease Deals

Key Information

Transmission Manual

Fuel Type Diesel

Top Speed 56mph

0 - 62mph 0.00s

Engine Size 2.2litres

Data provided by CAP-HPI database - Ref# 56449

Options

Standard Equipment

Technical Data

Driver Convenience

Battery charge warning
Cruise control with variable speed limiter with fixed 56 mph speed limiter
Door open warning for cab doors
Gearshift indicator
Handbrake on warning light
Locking fuel cap
Low fuel warning light
Oil level indicator
Power steering (non variable)
Rear parking distance sensor
Rev counter, trip computer, water temperature and fuel guage
Seatbelt warning indicator
Telematics box for Free2Move Connect Fleet services

Entertainment

7" Colour touchscreen with DAB radio, integrated satellite navigation, Bluetooth handsfree, USB socket and steering wheel mounted controls
Mirrorscreen with Apple CarPlay and Android Auto

Exterior Features

Electric front windows
Halogen headlights with clear polycarbonate lenses
Laminated windscreen
Nearside sliding side loading door
Non automatic 2 speed intermittent front windscreen wipers
Remote headlight adjustment from facia
Side protection rubbing strips
Tinted windows
Twin lens door mirrors with electrically adjustable and heated upper mirror

Interior Features

10 tie-down hooks
Bulb out warning for side light,headlamp and indicators
Central dash folding clipboard
Drivers seat with height, rake, lumbar and reach adjustment, and drivers armrest, with storage compartment under seat
Load compartment interior light
Lower central glovebox with dashboard tablet holder
Magnet cloth upholstery
Manual air conditioning for cab area with glovebox
Non illuminated lockable glove box
Non slip hardwearing front cabin floor covering
Passenger grab handle
Reach adjustable steering column
Two cup holders and mobile phone storage in centre of lower dashboard
Two load area lights

Passive Safety

Driver's airbag

Security

High frequency remote control central locking with 3 button plip
Lights on alarm
Locking for cab
Perimetric alarm and deadlocks
Thatcham rolling transponder immobiliser
Visible Vehicle Identification Number (VIN)

Technical

ABS
Automatic emergency braking system
Electronic brake force distribution (EBFD)
Electronic Stability Control (ESC)
Hill start assist
Reinforced twin leaf rear suspension

Wheels

Steel wheel centre cap

Emissions - ICE

CO

0.013
HC

Not Available
HC+NOx

0.047
Noise Level dB(A)

71
NOx

0.043
Particles

0.0004
Standard Emissions

EURO 6
WLTP - CO2 (g/km) - Comb

219
WLTP - CO2 (g/km) - Comb - TEH

289
WLTP - CO2 (g/km) - Comb - TEL

219
WLTP - CO2 (g/km) - Extra High - TEH

345
WLTP - CO2 (g/km) - Extra High - TEL

185
WLTP - CO2 (g/km) - High - TEH

261
WLTP - CO2 (g/km) - High - TEL

181
WLTP - CO2 (g/km) - Low - TEH

278
WLTP - CO2 (g/km) - Low - TEL

199
WLTP - CO2 (g/km) - Medium - TEH

258
WLTP - CO2 (g/km) - Medium - TEL

179

Engine and Drive Train

Automatic Transmission

No
Bore

85
Catalytic Convertor

Yes
CC

2179
Compression Ratio

16.1:1
Cooling System

WATER
Cylinder Layout

IN-LINE
Cylinders

4
Engine Codes

DW12RUC
Engine Layout

FRONT TRANSVERSE
Engine Make

Not Available
Fuel Delivery

COMMON RAIL
Fuel Type

DIESEL
Gears

6 SPEED
Manual Transmission

Yes
Number of Valves

16
Stroke

96
Valve gear

DOHC

Fuel Consumption - ICE

EC

No
WLTP - FC (l/100km) - Comb - TEH

11
WLTP - FC (l/100km) - Comb - TEL

7
WLTP - FC (l/100km) - Extra High - TEH

12.8
WLTP - FC (l/100km) - Extra High - TEL

7
WLTP - FC (l/100km) - High - TEH

10
WLTP - FC (l/100km) - High - TEL

6.9
WLTP - FC (l/100km) - Low - TEH

10.5
WLTP - FC (l/100km) - Low - TEL

7.7
WLTP - FC (l/100km) - Medium - TEH

9.9
WLTP - FC (l/100km) - Medium - TEL

6.8
WLTP - MPG - Comb - TEH

25.6
WLTP - MPG - Comb - TEL

40.1
WLTP - MPG - Extra High - TEH

22
WLTP - MPG - Extra High - TEL

40.3
WLTP - MPG - High - TEH

28.3
WLTP - MPG - High - TEL

40.9
WLTP - MPG - Low - TEH

26.9
WLTP - MPG - Low - TEL

36.5
WLTP - MPG - Medium - TEH

28.5
WLTP - MPG - Medium - TEL

41.4

General

Alternative Fuel Qualifying

No
Did at least one aspect of this vehicles safety give cause for concern?

No
Badge Engine CC

2.2
Badge Power

165
Based On ID

Not Available
Battery Volts

12
Chassis Engine Number

Not Available
Clutch

SINGLE DRY PLATE
Coin Description

Not Available
Coin Gross Vehicle Weight Code

Not Available
Coin Power Output Code

Not Available
Coin Series

Not Available
Coin Wheelbase Description Code

Not Available
Coin Wheelbase Name Code

Not Available
Exhaust System

CATALYTIC CONVERTER
Front Brakes

VENTILATED DISCS
Front Suspension

MACPHERSON STRUTS
Generation Mark

2
Ghost model for valuation purposes

No
Hand Brake

REAR DRUMS
Insurance Group 1

Not Available
Insurance Group 2

Not Available
Manufacturers Corrosion Perforation Guarantee - Years

6
Manufacturers Paintwork Guarantee - Years

1
NCAP Adult Occupant Protection %

Not Available
NCAP Child Occupant Protection %

Not Available
NCAP Overall Rating - Effective February 09

Not Available
NCAP Pedestrian Protection %

Not Available
Rear Brakes

DISCS
Rear Suspension

LEAF SPRINGS
Relative Height

H2
Relative Length

L4
Running Cost League Headings

LARGE
Service Interval Frequency - Months

24
Service Interval Mileage

32000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

Unlimited
Standard manufacturers warranty - Years

2
Steering

PAS RACK AND PINION
Vehicle Homologation Class

N2
Vin/Frame No.

Not Available

Performance

0 to 62

Not Available
BHP

165
Engine Power KW

121
Engine Power RPM

3750
Engine Torque LBS.FT

273
Engine Torque MKG

37.7
Engine Torque NM

370
Engine Torque RPM

1750
Top Speed

56

Test Cycles

Emissions Test Cycle

WLTP
RDE Certification Level

RDE 2

Tyres

Alloys?

No
Automatic Clutch

No
Plated 3rd Axle

Not Available
Plated 4th Axle

Not Available
Space Saver?

No
Tyre Make

Not Available
Tyre Size Front

225/75 R16
Tyre Size Rear

225/75 R16
Tyre Size Spare

TYRE REPAIR KIT
Wheel Style

Not Available
Wheel Type

16" STEEL

Vehicle Dimensions

Front Overhang

948
Height

2522
Height (including roof rails)

Not Available
Length

6363
Load Height

1932
Load Length

4070
Load Space Width Between Wheel Arches

1422
Load Width

1870
Lower Rear Door Width

1562
Rear Door Height

1790
Rear Overhang

1380
Side Load Door Height

1755
Side Load Door Width

1250
Turning Circle - Kerb to Kerb

14.24
Turning Circle - Wall to Wall

14.46
Upper Rear Door Width

1562
Wheelbase

4035
Width (excluding mirrors)

2050
Width (including mirrors)

2508

Weight and Capacities

Boot Capacity Saloons

Not Available
Fuel Tank Capacity (Litres)

90
Gross Train Weight

6505
Gross Vehicle Weight

4005
Load Space Volume

15
Luggage Capacity (Seats Down)

Not Available
Luggage Capacity (Seats Up)

Not Available
Luggage Capacity - 2nd Row Seats Removed

Not Available
Luggage Capacity - 2nd Row Seats Up

Not Available
Luggage Capacity - 3rd Row Seats Down

Not Available
Luggage Capacity - 3rd Row Seats Removed

Not Available
Luggage Capacity - 3rd Row Seats Up

Not Available
Max. Roof Load

100
Max. Towing Weight - Braked

2500
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

2135
No. of Seats

3
Payload

1870
Plated 2nd Axle

2400
Plated Front Axle

2100
